PRODUCT FEATURES:
1. Premium seamless HD video wall, no granular sense at short viewing distance, optimal substitute for LCD wall,DLP and LCD display, all-new display terminal for conference, command, deployment, monitoring and presentation.
2. The quality full black LEDs, together with the black mask, achieves clear and crystal picture.
3. The most advanced S-PWM driving technology for the LED display circuit brings picture more sense of layers.
4. 14-16 Bit gray scale. Perfect gray scale will remain when the screen brightness is reduced to 20%.
5. LEDs with lower power consumption and PFC power suppliers with 4.2V working voltage will save over 15% of energy compared with traditional models.
6. User-friendly locking system makes easy and convenient disassembly and maintenance.
7. Redundancy backup of signals and connectors and double backup for circuits improve the screen’s stability much.
8. Seams can be finely adjusted with exclusive Octopus which means connectors with 8 claws so that bright and dark lines among cabinets can be quickly removed.
9. 3840Hz refresh rate ensures pictures without waves, flickers or shake.
TECHNICAL PARAMETERS:
| Technical Parameters | UHD0.93 | UHD1.25 | UHD1.56 | UHD1.875 |
| Pixel Pitch | 0.9375mm | 1.25 mm | 1.56 mm | 1.875mm |
| Pixel Density | 1,137,777dots/m2 | 640,000dots/m2 | 409,600dots/m2 | 284,444dots/m2 |
| Pixel Configuration | 1R1G1B 3IN1/Mini LED | 1R1G1B 3IN1/SMD1010 | 1R1G1B 3IN1/SMD1010 | 1R1G1B 3IN1/SMD1010 |
| Module Size |
150X168.75mm |
|||
| Standard Cabinet Size |
600X337.5X34mm |
|||
| Standard Cabinet Weight |
4.2KG |
|||
| Viewing Angle |
160°HX160°V |
|||
| Grey Scale |
≥14 bit 16,384 levels |
|||
| Max.Refresh Rate |
≥3840 Hz |
|||
| Contrast Ratio |
5000:1 |
|||
|
Protection Level |
IP30 |
|||
| Max. Brightness |
400-800cd adjustable |
|||
| Frame Frequency |
50/60Hz |
|||
| Scan Method | 1/64 dynamic | 1/60 dynamic | 1/54 dynamic | 1/40 dynamic |
| Best Viewing Distance |
1-150m |
|||
| Ave.Power Consumption |
300w/m2 |
|||
| Max.Power Consumption |
800w/m2 |
|||
| Display Color Qty. |
16,777,216 |
|||
| Color Temperature |
2000-9500K adjustable |
|||
| Working Temperature |
-10℃~+60℃ |
|||
|
Storage Temperature |
-20℃~+85℃ |
|||
| Operation Humidity |
10%~90% RH |
|||
| Continuous Working Time |
≥24 Hrs |
|||
| MTBF |
≥5,000 Hrs |
|||
| Display Lifespan |
≥100,000 Hrs |
|||
| Control Distance |
Ethernet:Max.100m/Multi-fiber:Max.500m/Single-fiber:Max.10KM |
|||
| Flatness |
Screen Surface Gap<0.5mm/Pixel Pitch Gap<0.3mm |
|||
| Protection System |
Overtemperature/load/overpower/image compensation/nonlinear correction |
|||
| Control Mode |
Synchronous Control with DVI interface |
|||
| Display Media |
Text,Animation,Graphic,Video and so on |
|||
| Signal Source |
Composite,S-video,Compent,VGA,DVI,HDMI,HD-SDI |
|||
| System Operating Platform |
Windows98/2000/XP/7/8/10 |
|||
| Warranty Period |
2 Years |
|||
