PRODUCT FEATURES:
1. Fast and Flexible Assembling: Pad installation or track holding installation are both available.
2. High Bearing:Maximum 1500kg/SQM weight loading with die-casting aluminum structure.
3. Friendly Maintenance:Convenient repair by special hang out tool even fixed in ground.
4. IP65: Anti-water,Anti-drinks spill, anti-slip, easy to clean.
5. High Contrast Ratio: Patented mask design makes clear images.
6. Excellent Cooling Design: Professional cooling design, ensure a perfect heat dissipation.
7. Outstanding effects: Even 20% brightness, the gray uniformity & display consistency are still good.
TECHNICAL PARAMETERS:
| Technical Parameters | FLOOR5.2 | FLOOR6.25 | FLOOR8.9 |
| Pixel Pitch | 5.2 mm | 6.25mm | 8.9mm |
| Pixel Density | 36,864dots/m2 | 25,600dots/m2 | 12544dots/m2 |
| Pixel Configuration | 1R1G1B 3in1/SMD1921 | 1R1G1B 3in1/SMD2525 | 1R1G1B 3in1/SMD3535 |
| Module Size | 250x250mm | ||
| Standard Cabinet Size | 500x500mm or 500x1000mm | ||
| Standard Cabinet Weight | 12 KG/PCS or 24KG/PCS | ||
| Viewing Angle | 120°HX120°V | ||
| Grey Scale | ≥14 bit 16,384 levels | ||
| Max.Refresh Rate | ≥1440 Hz | ||
| Contrast Ratio | 4000:1 | ||
| Protection Level | Indoor IP43/Outdoor IP65 | ||
| Max.Brightness | Indoor 2000cd/Outdoor 5000cd | ||
| Frame Frequency | 50/60Hz | ||
| Scan Method | 1/6 dynamic scanning | 1/5 dynamic scanning | 1/4 dynamic scanning |
| Best Viewing Distance | 5-150m | 6-200m | 8-200m |
| Ave.Power Consumption | 400w/m2 | 400w/m2 | 400w/m2 |
| Max.Power Consumption | 800w/m2 | 800w/m2 | 800w/m2 |
| Display Color Qty. | 16,777,216 | ||
| Color Temperature | 2000-9500K adjustable | ||
| Working Temperature | -10℃~+60℃ | ||
| Storage Temperature | -20℃~+85℃ | ||
| Operation Humidity | 10%~90% RH | ||
| Continuous Working Time | ≥24 Hrs | ||
| MTBF | ≥5,000 Hrs | ||
| Display Lifespan | ≥100,000 Hrs | ||
| Control Distance | Ethernet:Max.100m/Multi-fiber:Max.500m/Single-fiber:Max.10KM | ||
| Flatness | Screen Surface Gap<0.5mm/Pixel Pitch Gap<0.3mm | ||
| Protection System | Overtemperature/ overload/ overpower/ image compensation/ nonlinear correction | ||
| Control Mode | Synchronous Control with DVI interface | ||
| Display Media | Text/ Animation/ Graphic/ Video and so on | ||
| Signal Source | Composite/ S-video/ Compent/ VGA/ DVI/ HDMI/ HD-SDI | ||
| System Operating Platform | Windows98/2000/XP/7/8/10 | ||
| Warranty Period | 2 Years | ||
