CABINET FEATURES:
1. Maximum 60-80% high transparency, backside visible.
2. 5KG/PCS light-weight cabinet, very easy to move & install & dismantle
3. Min.1cm quite slim surface design, very clean & nice appearance
4. Max.5000nits high & adjustable brightness, meet different requirements of varieties of occasions.
5. Fast locking system design, quick & easy installation, save labor & time for rental and fixed use both.
6. Convenient serviceability, individually removable and replaceable, easy maintenance.
TECHNICAL PARAMETERS:
| Technical Parameters | CLEAR 3.9 | CLEAR 5.2 | CLEAR 10 | CLEAR 12 |
| Pixel Pitch | H 3.9/V 7.8 mm | H 5.2/V10.4mm | 10.4mm | 12.5mm |
| Pixel Density | 32,768dots/m2 | 18,432dots/m2 | 9216dots/m2 | 6400dots/m2 |
| Pixel Configuration | 1R1G1B 3in1/SMD2020 | 1R1G1B 3in1/SMD2020 | 1R1G1B 3in1/SMD1921 | 1R1G1B 3in1/SMD1921 |
| Module Size | 250×62.48mm | 250×83.36mm | 250×41.66mm | 250x50mm |
| Standard Cabinet Size | 500x500mm or 500x1000mm | |||
| Standard Cabinet Weight | 5kg/piece or 10kg/piece | |||
| Viewing Angle | 140°HX140°V | |||
| Grey Scale | ≥14 bit 16,384 levels | |||
| Max.Refresh Rate | ≥1920 Hz | |||
| Contrast Ratio | 4000:1 | |||
| Protection Level | IP30 | |||
| Max. Brightness | 800-1000cd | 900-1200cd | 900-1200cd | 900-1200cd |
| Transparency | 45% | 50% | 55% | 60% |
| Frame Frequency | 50/60Hz | |||
| Scan Method | 1/16 dynamic | 1/12 dynamic | 1/6 dynamic | 1/5 dynamic |
| Best Viewing Distance | 3-150m | 5-150m | 10-300m | 12-300m |
| Ave.Power Consumption | 200w/m2 | 200w/m2 | 200w/m2 | 200w/m2 |
| Max.Power Consumption | 500w/m2 | 500w/m2 | 500w/m2 | 500w/m2 |
| Display Color Qty. | 16,777,216 | |||
| Color Temperature | 2000-9500K adjustable | |||
| Working Temperature | -10℃~+60℃ | |||
| Storage Temperature | -20℃~+85℃ | |||
| Operation Humidity | 10%~90% RH | |||
| Continuous Working Time | ≥24 Hrs | |||
| MTBF | ≥50,000 Hrs | |||
| Display Lifespan | ≥100,000 Hrs | |||
| Control Distance | Ethernet:Max.100m/Multi-fiber:Max.500m/Single-fiber:Max.10KM | |||
| Flatness | Screen Surface Gap<0.5mm/Pixel Pitch Gap<0.3mm | |||
| Protection System | Overtemperature/ overload/ overpower/ image compensation/ nonlinear correction | |||
| Control Mode | Synchronous Control with DVI interface | |||
| Display Media | Text/ Animation/ Graphic/ Video and so on | |||
| Signal Source | Composite/ S-video/ Compent/ VGA/ DVI/ HDMI/ HD-SDI | |||
| System Operating Platform | Windows98/2000/XP/7/8/10 | |||
| Warranty Period | 2 Years | |||
